Line Heaters

Rental 2 mmbtu 4" 4,500 psi Sour Line Heaters

In stock - Inventory item 11441

Product Snapshot

For use anytime hydrating or freezing is a concern. Roska line heaters are modern, electronically controlled systems fully compliant with CSA B149.3, including a burner management system with 1-second response. A leap beyond legacy pneumatically controlled line heaters. System includes high- and low-temperature and low-glycol, flame-fail shut-downs. Similar design to the 3" line heater model.



Features   Benefits

Indirect Fired Process Heater 2,000,000 btu/hr
  20” Firetube with flame arrested burner
  60” x 16’ Insulated bath
  Winch Load with heavy duty skid
  Insulated instrument enclosure
CSA B149.3 Code Compliant Profire 2100 Burner Management System (BMS) class 1, div2
Split Bundle 4” XXH coils with cl2500 RTJ flanged connections
  Optional chokes available



Product Specifications
Design Pressure   4,500 psi @ 200° F
MDMT   -50° F
Radiography   100%
PWHT   Yes
Dimensions   30’-1” L x 7’-6” W x 8’-3” H
Weight   22,000 lb
Service   Sour
