Separator

36" x 10' 1,440 psi Sour Vertical Separator

In stock - Inventory item 11402

Product Snapshot

For high-rate, multi-phase wells. Our most popular separator, providing individual metering of gas, oil and water. With many Montney and Duvernay wells being in newer, less well delineated areas, numerous wells come in sour. This sour-capable separator ensures you are ready! Built with the same design advantages as our smaller, 30” X 10’ vertical sour separator.



Features   Benefits

3 Phase Fluids Separation and Flow Measurement For early-stage production evaluation
Electronic Flow Metering (EFM) Accurate and SCADA compatible
36” diameter Separation capacity to handle high rate wells such as those in the Duvernay and Montney
Fisher Controls Offer superior control reliability and inter-connectivity
Sr Daniels Meter Run 4” cl600 Enables high rate gas flow measurement at low pressure
Fuel Gas Scrubber with exclusive Coalescing Filter For improved separation efficiency
Fuel Gas Meter For compliant or accurate production accounting
Twin 24”x24” Cata-Dyne Heaters Improves operability in cold temperatures
3” ET Valve with I to P Flexible, fast, accurate and reliable flow control
Epoxy Paint Included for corrosion protection



Product Specifications
Design Pressure   1,440 psi @ 130° F
MDMT   -20° F
Radiography   100%
PWHT   Yes
Dimensions   LxWxH 18’ x 8’ x 11’-5"
Weight   16,800 lb
Service   Sour
