In stock - Inventory item various
This critical form of over-pressure protection on the well site is part of the Roska rental inventory. Our hydraulically actuated, spring-loaded ESDs come with the actuator and the high- and low-pressure sensors built-in for quick and convenient installation of the ESD at your well site.
| Features | Benefits | |
|---|---|---|
| 2” to 4” Nominal Pipe Size | Gate valve with fail closed hydraulic actuator | |
| Hi/Lo Pilot | Hi pressure switch, low pressure switch, aux electric relay input | |
| cl2500 or cl1500, 10,000API Flanged | Variety of brands in stock | |
| Sour Service | For H2S service | |
| NACE MR0175 | ||
| Low Temperature | ||
| Design Pressure | To 10,000 psi | |
| MDMT | -50° F | |
| Radiography | N/A | |
| PWHT | N/A | |
| Dimensions | varies | |
| Weight | varies | |
| Service | sour |
